In VMware Horizon, predefined roles such as Inventory Administrators and Desktop Pool Administrators are designed to provide granular access control within the Horizon Console. Inventory Administrators typically have permissions related to managing the overall inventory of virtual desktops and applications, whereas Desktop Pool Administrators are specifically focused on managing and configuring desktop pools, including their settings, assignments, and provisioning.

The issue described indicates that the Horizon Connection Server is incorrectly handling traffic that should be directed to the Unified Access Gateway (UAG) and then to the VDI desktops. Disabling the Tunnel and Gateways settings on the Horizon Connection Server forces the UAG to handle the Blast traffic directly, ensuring that the connections are made to the VDI desktops' IP addresses, thus resolving the black screen and disconnection issue.

C:\Users\Waqas Shahid\Desktop\Mudassir\Untitled.jpg

• SAML -> Connects the client to Workspace ONE Access
• Certificate Authority -> Issues certificates for vrm and Enrollment Server
• Connection Server -> Connects vrm to Active Directory
• Enrollment Server -> Connects Workspace ONE Access to vrm

You can find more information about the Simple True 5SO Architecture in the VMware Horizon 8.x Professional source documents or study guide1. This architecture is a simplified version of the True SSO Architecture, which allows users to log in to their virtual desktops and applications without entering credentials multiple times. The Simple True 5SO Architecture uses Workspace ONE Access as the identity provider, which authenticates users with SAML and issues SAML assertions. The Enrollment Server then uses the SAML assertions to request short-lived certificates from the Certificate Authority, which are used to authenticate users to the Connection Server. The Connection Server then connects users to their virtual desktops and applications through vrm, which is integrated with Active Directory2.

References:

• VMware Horizon 8.x Professional
• Simple True SSO Architecture

To monitor the advanced metrics of desktop sessions in Horizon Console, you need to use the Horizon Help Desk Tool. This is a web application that you can use to get the status of Horizon 8 user sessions and to perform troubleshooting and maintenance operations1. You can also view performance details for a virtual or published desktop session that uses the PCoIP or VMware Blast display protocol2.

To access the Horizon Help Desk Tool, you need to click on the Monitoring tab on the left side of the Horizon Console. Then, you need to select Help Desk from the drop-down menu. This will open the Horizon Help Desk Tool in a new browser tab. You can then search for a user, machine, or pool and view the session details. You can also click on More to see the advanced metrics such as latency, bandwidth, protocol, and frame rate1.

To enable debug logging for a single user in VMware Dynamic Environment Manager, the administrator needs to create an empty FlexDebug.txt file in the same folder as the standard log file for this user. This will trigger FlexEngine to switch to debug logging for this particular user1. Debug logging is useful for troubleshooting purposes, as it provides more detailed information about the FlexEngine operations and actions1.

The other options are not correct because:

• Updating the FlexEngine registry to DEBUG will not enable debug logging for a single user, but for all users who log on to the same computer. This option can only be set through Group Policy settings and applies to all users1. Moreover, this option is not recommended, as it can cause performance issues and disk space consumption due to the large size of the log files1.
• Creating an empty FlexDebug.log file in the log folder will not enable debug logging for a single user, as the file name must be exactly FlexDebug.txt. The file extension must be .txt, not .log1.
• Configuring the FlexEngine GPO to DEBUG will not enable debug logging for a single user, but for all users who are affected by the GPO. This option can only be set through Group Policy settings and applies to all users1. Moreover, this option is not recommended, as it can cause performance issues and disk space consumption due to the large size of the log files1.

References:

• Enabling debug logging for a single user in VMware Dynamic Environment Manager1

In VMware Horizon, to designate a Home Site for a user, you would use the "Cloud Pod Architecture" feature, which allows you to set home sites and manage global entitlements across multiple pods and sites in a Horizon environment.

In the exhibit's menu on the left, you should click on "Cloud Pod Architecture" to proceed with designating a Home Site for a user.

The two options that are available for the administrator to make the shortcut available to all desktop pool users, while minimizing ongoing administrative effort, before updating the desktop pool golden image are:

• Copy the shortcut to c:\users\Public\Desktop. This option will place the shortcut in the public desktop folder, which is shared by all users who log on to the same computer. The public desktop folder is normally a hidden folder, so the administrator needs to enable the option to show hidden files and folders in File Explorer1. This option does not require any additional software or configuration, but it will only work for the existing desktops in the pool. If new desktops are added or refreshed, the shortcut will not be copied automatically.
• Configure a Shortcut with DEM (Dynamic Environment Manager). This option will use the DEM console to create a shortcut configuration that will apply the shortcut to the user’s desktop during logon2. The administrator needs to install and configure DEM on the Horizon environment, and create a configuration share and a profile archive share for storing the DEM settings3. This option requires more initial setup, but it will work for any desktop in the pool, regardless of whether it is new or refreshed. It also allows more flexibility and control over the shortcut properties and conditions.

The other options are not valid or feasible because:

• Copying the shortcut during user provisioning to a non-writeable App Volume will not work because App Volumes are used to deliver applications, not shortcuts. App Volumes are virtual disks that are attached to the virtual machines at runtime, and they contain application files, registry entries, and settings4. Copying a shortcut to an App Volume will not make it appear on the user’s desktop.
• Copying the shortcut to the Windows Default Domain Controller Policy will not work because this policy is used to configure settings for domain controllers, not desktops. The Default Domain Controller Policy is a Group Policy Object (GPO) that is linked to the Domain Controllers organizational unit (OU) in Active Directory, and it contains security settings that are applied to all domain controllers in the domain5. Copying a shortcut to this policy will not affect any desktops in the Horizon environment.
• Configuring a Shortcut with Horizon View Client will not work because Horizon View Client is used to connect to remote desktops and applications, not to create shortcuts. Horizon View Client is a software application that runs on various devices and platforms, and it allows users to access their virtual desktops and applications through a secure connection6. Configuring a shortcut with Horizon View Client will not make it appear on the user’s desktop.

References:

• How to make a desktop shortcut available for all users in Windows 101
• VMware Dynamic Environment Manager (DEM) 2306 – Carl Stalhood2
• VMware Tech Zone Antivirus Considerations in a VMware Horizon Environment: exclusions for Horizon View, App Volumes, User Environment Manager, ThinApp3
• App Volumes Overview
• Default Domain Controller Policy5
• VMware Horizon Clients Documentation6

To correctly sequence the TLS Certificate Configuration Steps:

• Get a new signed TLS certificate from a CA. Before making any modifications or importing the certificate, you'll first need to obtain a new signed TLS certificate from a Certificate Authority (CA). So, this should be Step 1.
• Import the TLS certificate into the Windows local computer certificate store. After obtaining the new signed TLS certificate, the next logical step is to import this certificate into the Windows local computer certificate store. This would be Step 2.
• Modify the certificates/ friendly names to vdm and reflect the current active certificate. Once the certificate is imported, the next step is to modify its friendly names to ensure the Horizon Service recognizes and uses this certificate. This becomes Step 3.
• Restart Horizon Service. Finally, after all the modifications and configurations are done, you should restart the Horizon Service to apply the changes. This is Step 4.

In summary:
