350-701 Exam Dumps - Implementing and Operating Cisco Security Core Technologies (SCOR 350-701)

RADIUS Change of Authorization (CoA) is a feature of Cisco ASA that allows VPN users to be postured against Cisco ISE without requiring an inline posture node. RADIUS CoA enables the ISE to send a message to the ASA to change the authorization attributes of an existing VPN session, such as the assigned IP address, ACL, or group policy. This way, the ISE can dynamically adjust the access level of the VPN user based on the posture assessment results, without the need for an intermediate device to enforce the policy change12. RADIUS CoA is supported by the ASA since version 9.2.13. References: 1: ASA Version 9.2.1 VPN Posture with ISE Configuration Example - Cisco 2: How To: ISE and ASA Integration using CoA for Posture - Cisco Community 3: How To Configure Posture with AnyConnect Compliance … - Cisco CommunityQUESTION NO: 94

What two mechanisms are used to redirect users to a web portal to authenticate to ISE for guest services?(Choose two)A. multiple factor authB. local web authC. single sign-onD. central web authE. TACACS+

Answer: B, D

 Local web authentication (LWA) and central web authentication (CWA) are two mechanisms that are used to redirect users to a web portal to authenticate to ISE for guest services. Both methods involve the use of a redirect access control list (ACL) that allows the user to access only the web portal URL and blocks all other traffic until the user is authenticated. The difference between LWA and CWA is where the web portal and the authentication logic are hosted.

• LWA: The web portal and the authentication logic are hosted on the wireless LAN controller (WLC). The WLC sends a RADIUS access-accept message to the network access device (NAD) along with the redirect ACL and the web portal URL. The NAD then redirects the user to the web portal on the WLC, where the user enters their credentials. The WLC verifies the credentials with the ISE and grants or denies access to the user. The advantage of LWA is that it does not require any configuration on the ISE, but the disadvantage is that it does not support advanced features such as posture assessment, profiling, or authorization policies.
• CWA: The web portal and the authentication logic are hosted on the ISE. The WLC sends a RADIUS access-challenge message to the NAD along with the redirect ACL and the web portal URL. The NAD then redirects the user to the web portal on the ISE, where the user enters their credentials. The ISE verifies the credentials and sends a RADIUS access-accept message to the WLC with the authorization profile and the final ACL. The WLC then applies the authorization profile and the final ACL to the user session. The advantage of CWA is that it supports advanced features such as posture assessment, profiling, or authorization policies, but the disadvantage is that it requires more configuration on the ISE.

References :=

• Configure Guest Access
• Web Authentication Redirection to Original URL
• Configure Local Web Authentication with External Authentication

Cisco Identity Services Engine (ISE) is a product that provides comprehensive and scalable access policy enforcement for wired and wireless networks. ISE supports TACACS+ for device administration, which allows for granular control over the commands and actions that network administrators can perform on network devices. ISE also supports 802.1X, MAB, and WebAuth for network access, which enables authentication and authorization of users and endpoints based on various attributes, such as identity, device type, posture, location, and time. ISE can also integrate with other Cisco security products, such as Cisco Stealthwatch and Cisco AMP for Endpoints, to provide enhanced visibility and threat detection. Therefore, ISE is the product that meets all of the requirements stated in the question. References :=

Some possible references are:

• Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0, Module 4: Secure Network Access, Identity Management, and Secure Access
• TACACS+ Configuration Guide, Configuring TACACS
• Cisco Identity Services Engine Administrator Guide, Release 2.7, Device Administration
• Cisco Identity Services Engine Administrator Guide, Release 2.7, Network Access Devices
• Cisco Identity Services Engine Administrator Guide, Release 2.7, Policy Sets

Time synchronization is one of the features that can be configured for managed devices in the device platform settings of the Firepower Management Center (FMC). Time synchronization ensures that the FMC and its managed devices have the same date and time settings, which is important for accurate event logging and reporting. The FMC can act as a Network Time Protocol (NTP) server for its managed devices, or it can use an external NTP server as a time source1. The FMC can also synchronize its time with the system clock of the device where it is installed2. References := 1: Firepower Management Center Device Configuration Guide, 7.1 - Platform Settings 2: Firepower Management Center Configuration Guide, Version 6.6 - Device Management Basics

ExplanationPing of Death (PoD) is a type of Denial of Service (DoS) attack in which an attacker attempts to crash,destabilize, or freeze the targeted computer or service by sending malformed or oversized packets using a simple ping command.A correctly-formed ping packet is typically 56 bytes in size, or 64 bytes when the ICMP header is considered,and 84 including Internet Protocol version 4 header. However, any IPv4 packet (including pings) may be as large as 65,535 bytes. Some computer systems were never designed to properly handle a ping packet larger than the maximum packet size because it violates the Internet Protocol documentedLike other large but well-formed packets, a ping of death is fragmented into groups of 8 octets beforetransmission. However, when the target computer reassembles the malformed packet, a buffer overflow can occur, causing a system crash and potentially allowing the injection of malicious code.

Cisco FTDv in AWS can be deployed in two different deployment models: single-instance and cluster. In both models, the FTDv can be configured in routed mode and managed by either an FMCv installed in AWS or a physical FMC appliance on premises. The FTDv can also use Geneve encapsulation for traffic interfaces to support AWS Gateway Load Balancer (GWLB) integration. The following table summarizes the supported deployment model configurations for FTDv in AWS:

Table

Deployment Model

Management Mode

Traffic Mode

Geneve Encapsulation

Single-instance

FMCv in AWS

Routed

Optional

Single-instance

FMC on premises

Routed

Optional

Cluster

FMCv in AWS

Routed

Required

Cluster

FMC on premises

Routed

Required

References :=

• Deploy the Threat Defense Virtual on AWS - Cisco
• Deploy a Threat Defense Virtual Cluster on AWS - Cisco
• Configure Geneve Interfaces in Secure FTDv - Cisco
• Deployment of Cisco Secure FTDv and FMCv instances in AWS - Terraform
• Solved: FTD virtual appliance in AWS - Cisco Community

 Firepower NGIPS inline deployment mode is a mode where the NGIPS device is placed in the traffic path and can take actions such as blocking, modifying, or redirecting traffic based on the policies and rules. In this mode, the NGIPS device must have inline interface pairs configured, which are pairs of physical or logical interfaces that act as a single logical interface. The inline interface pairs are connected to the network devices on both sides of the NGIPS device, and the traffic flows through the NGIPS device from one interface to the other. The NGIPS device can inspect and modify the traffic as it passes through the inline interface pairs12. References := 1: Firepower Management Center Configuration Guide, Version 6.6 - Device Management Basics 2: Configure FTD Interfaces in Inline-Pair Mode

The Cloudlock Apps Firewall is a feature of Cisco Cloudlock, which is a cloud-native cloud access security broker (CASB) that helps organizations move to the cloud safely. The Cloudlock Apps Firewall mitigates security concerns from an application perspective by discovering and controlling cloud apps that are connected to a company’s corporate environment, such as Google G Suite or Microsoft Azure Active Directory (AD). These cloud apps are authorized through OAuth to access corporate data and resources via APIs, and may pose risks such as data exfiltration, account compromise, or malicious behavior. The Cloudlock Apps Firewall provides visibility into the app ecosystem, including the app name, category, risk level, access scopes, and number of users. It also allows administrators to ban or allowlist apps based on their risk profile and compliance requirements. Additionally, the Cloudlock Apps Firewall leverages a crowd-sourced Community Trust Rating for each app, which reflects the feedback from other Cloudlock customers on the app’s security and functionality. References :=

• Cisco Content Security Products
• Cisco Cloudlock - Cisco
• Shadow IT Control with Apps Firewall - Cisco
• Test scor q151 - q200
