For the NC2 cluster deployed in the North Virginia region (us-east-id), consuming IPs from the 10.78.2.0/24 range, the subnets configured within the same CIDR range of 10.78.0.0/16 will be recognized.

The subnetDR01 (10.78.2.0/24)is directly within the range of the deployed cluster.

The subnetL2stretch (10.19.101.0/24)is also configured in the NC2 AWS VPC, although not in the immediate range of the cluster, it may show up due to broader network configurations for stretched L2 operations.

SubnetsVDI (10.78.130.0/22)andDR02 (10.79.120.0/24), although part of the same VPC, are not directly within the immediate CIDR range or may not be recognized in this specific configuration scenario.

References:Refer to the Nutanix documentation on NC2 AWS VPC subnet configurations and Prism Element settings for detailed guidelines on network visibility and configuration.

When a node is marked as "Condemned," it indicates that the system has determined that the node is no longer reliable for operations. As part of the automated recovery and protection process, the following action is typically taken:

The node has a power reset sent to it (Answer A):

In most cases, a condemned node undergoes a power reset as an initial recovery attempt. This action attempts to reboot the node to bring it back to a healthy state. If the reset fails,further manual or automated steps may be required to address the hardware or software issue.

References:

Nutanix Cluster Management Documentation

Nutanix Support Knowledge Base

To manually create an AWS VPC with Public access to Prism Element for testing purposes, the following components must be created:

VPC: A Virtual Private Cloud to provide an isolated network for the resources.

Delegated Subnets: Subnets within the VPC to segment the network and allocate IP ranges.

Route Tables: To define routing rules for the subnets to ensure proper traffic flow.

NAT Gateway: To enable instances in the private subnets to access the internet.

Internet Gateway: To allow direct internet access to instances in the public subnets.

Load Balancer: To distribute traffic across multiple instances for improved availability and redundancy.

References:Refer to the AWS documentation on VPC creation and Nutanix documentation on network setup for Prism Element access.

To enable inbound internet access to Virtual Servers in an NC2 cluster on AWS for the HTTPS protocol, the administrator should use an AWS Network Load Balancer (NLB).

Configure the NLB listener to listen on TCP port 443, which is the standard port for HTTPS traffic.

Create a target group in AWS, and register the servers (Virtual Servers in the NC2 cluster) as targets within this group.

Ensure the NLB is properly configured with an Elastic IP (EIP) if required, to provide a static IP address for the load balancer.

Verify that the security groups and network ACLs associated with the load balancer and the target group allow inbound traffic on port 443.

References:Refer to AWS documentation on Network Load Balancers and Nutanix NC2 on AWS integration guides for step-by-step instructions on setting up and configuring the necessary components for enabling HTTPS access.

The 192.168.5.0/24 range is often reserved for internal cluster communication within Nutanix deployments.

Using this CIDR range for other purposes could lead to network conflicts and connectivity issues, as it might interfere with the internal operations and communication channels of the Nutanix cluster.

Ensuring that the CIDR range is not overlapping with any reserved ranges is crucial for maintaining proper network connectivity and cluster functionality.

References:Refer to the Nutanix documentation on network configuration and best practices for NC2 deployments to confirm reserved IP ranges and their appropriate use.

For VDI workloads that require GPU acceleration, the g4dn.metal nodes are the appropriate choice. These instances are equipped with NVIDIA T4 GPUs, which are well-suited forgraphics-intensive applications such as VDI workloads that need GPU acceleration. Other node types like AN36P, m6g.metal, or AN36 do not provide the necessary GPU capabilities.

References:

Nutanix Support & Insights - GPU support in AWS

The NC2 Tile within the my.nutanix.com portal is the correct interface to deploy NC2. This portal provides an integrated and user-friendly interface specifically designed for deploying and managing Nutanix Clusters on AWS.

NC2 Deployment Interface:

NC2 Tile within the my.nutanix.com portal: This portal provides the necessary tools and options to deploy and manage NC2 clusters. It includes functionalities for setting up the clusters, configuring network settings, and managing resources.

Advantages:

User-Friendly Interface: Simplifies the deployment process with a guided setup.

Integrated Tools: Provides access to all necessary tools for managing the deployment and monitoring of NC2 clusters.

References:

Nutanix Cloud Clusters on AWS Administration Guide

Nutanix my.nutanix.com Portal Documentation

Nutanix Best Practices for Cluster Deployment

To establish full connectivity between the company’s on-premises datacenter and the AWS cloud, the following AWS offerings will satisfy this requirement:

AWS VPN: This service allows you to create a secure connection between your on-premises network or other remote network and your AWS VPC using an IPsec VPN tunnel. It is suitable for low to moderate bandwidth requirements and provides secure, encrypted connections.

Direct Connect: AWS Direct Connect is a dedicated network connection from your premises to AWS. It provides a private, high-bandwidth, low-latency connection which is ideal for high-throughput applications and workloads that need consistent network performance.

References:

AWS VPN Documentation

AWS Direct Connect Documentation

Before accessing the Nutanix Cloud Clusters (NC2) console, the first step is to create a My Nutanix account.

This account serves as the primary gateway for managing and accessing Nutanix services, including NC2.

Once the account is created, users can log in to the Nutanix portal, where they can manage their subscriptions, start trials, and access various Nutanix services, including the NC2 console.

References:Refer to the Nutanix documentation on getting started with NC2 and the My Nutanix account creation process.

When creating user VM subnets for multiple NC2 clusters in AWS, the best approach is to create guest-VM subnets for each cluster. This ensures that each cluster has its own dedicated subnets, which simplifies network management and avoids potential IP conflicts.

Advantages of Dedicated Subnets:

Isolation: Each cluster operates in its own subnet, providing better isolation and security.

Management: Easier to manage and troubleshoot network issues when each cluster has its own subnets.

Scalability: More scalable as each subnet can be managed and expanded independently.

Steps to Create Guest-VM Subnets:

Identify the IP range for each subnet.

In the AWS VPC console, create a new subnet for each cluster using the identified IP ranges.

Associate the new subnets with the respective clusters during or after the cluster deployment process.

Why Not Shared Subnets:

Shared subnetscould lead to IP conflicts and make network management more complex, especially as the number of clusters grows.

References:

Nutanix Cloud Clusters on AWS Administration Guide

AWS VPC Subnet Creation Documentation

The maximum number of nodes supported in an NC2 cluster on AWS is 24 nodes. This limit ensures optimal performance and manageability within the AWS infrastructure while leveraging the benefits of the Nutanix architecture.

References:

Nutanix Clusters on AWS Deployment Guide

Nutanix Support & Insights

Cluster Protect in an NC2 environment can protect and recover the following services and their associated metadata:

VM Templates: Ensures that templates used for creating virtual machines are backed up and recoverable.

Files: Protects data stored in Nutanix Files, ensuring that file services are backed up and can be restored as needed.

References:

Nutanix Support & Insights

Nutanix Cloud Clusters on AWS Administration

To deploy an NC2 cluster using an existing AWS network, the NAT Gateway should be placed in a public subnet. A public subnet is one that has a route to an Internet Gateway, allowing the NAT Gateway to provide outbound internet access for resources in private subnets. The NAT Gateway is used to enable instances in private subnets to access the internet while keeping them secure by not exposing them directly to the public internet.

References:

Nutanix Cloud Clusters (NC2) on AWS Documentation

To manually hibernate an NC2 on AWS cluster, the administrator can use the following methods:

Select the cluster under NC2 console and Select Hibernate/Resume on the cluster sur page: Navigate to the specific cluster in the NC2 console and use the provided Hibernate/Resume option.

Log into NC2 console, find the cluster name and select Hibernate/Resume from the ellipses: Access the NC2 console, locate the cluster name, and select the Hibernate/Resume option from the ellipses (three dots) menu.

These options allow for the manual control of the cluster's hibernation state directly within the NC2 console interface.

References:

Nutanix Cloud Clusters on AWS Administration

Nutanix Support & Insights

To provide VMs with outbound internet connectivity in AWS using a private subnet, the administrator needs to create the following components in the VPC:

Private Subnet: A private subnet is required to house the VMs that need outbound internet access but do not require direct inbound access from the internet.

NAT Gateway: A NAT (Network Address Translation) Gateway is necessary to allow instances in the private subnet to connect to the internet or other AWS services while preventing the internet from initiating a connection with those instances.

Public EIP (Elastic IP Address): An EIP is associated with the NAT Gateway to provide a persistent public IP address that allows outbound internet traffic from the private subnet to be routed correctly.

Route Table: A route table is configured to route traffic from the private subnet to the NAT Gateway for outbound internet access.

References:

AWS NAT Gateway Documentation

AWS VPC Subnet Basics

To avoid IP address conflicts and ensure there are no configuration issues when reusing an existing AWS subnet, the administrator should take the following actions:

aCLI > net.add_to_ip_blacklist 10.79.4.200 aCLI > net.add_to_ip_blacklist 10.79.4.201 (Answer A):

This command adds the specified IP addresses to the blacklist, preventing AHV IPAM from assigning these addresses to any VMs. This ensures that the existing EC2 instances with IPs 10.79.4.200 and 10.79.4.201 are not allocated to other VMs in the NC2 cluster.

Configure the AHV IPAM to use DHCP range 10.79.4.2 -10.79.4.253 (Answer D):

By configuring the AHV IPAM to use a specific DHCP range, you ensure that the IP addresses assigned to the EC2 instances (10.79.4.200 and 10.79.4.201) are not included in the DHCP pool. This prevents IP address conflicts within the subnet.

References:

Nutanix aCLI Reference

Nutanix NC2 on AWS Documentation

AWS VPC and Subnet Basics

To ensure that NC2 VMs can access AWS resources without traversing the internet, the administrator can use AWS VPC Peering and Interface Endpoints. Both methods ensure that traffic stays within the AWS network, maintaining security and efficiency.

Interface Endpoint:

Interface Endpoints allow you to privately connect your VPC to supported AWS services. They use AWS PrivateLink to route traffic directly to services within the AWS network, bypassing the public internet.

Steps:

Create an interface endpoint for the required service in the AWS VPC console.

Ensure the security groups and route tables are configured to allow traffic to the interface endpoint.

VPC Peering:

VPC Peering allows the routing of traffic between VPCs using private IP addresses, without the need for internet gateways, NAT devices, or VPN connections.

Steps:

Create a VPC peering connection between the VPCs.

Update the route tables to direct traffic between the peered VPCs.

Ensure security group rules allow the necessary traffic between VPCs.

References:

AWS VPC Peering Documentation

AWS Interface Endpoint Documentation

Nutanix Cloud Clusters on AWS Administration Guide

To protect workloads on an NC2 cluster on AWS, deploying strategies that ensure high availability and disaster recovery are essential. The two valid options are:

Create a Second NC2 Cluster in a Different Availability Zone:

High Availability: Deploying a second NC2 cluster in a different availability zone ensures that workloads can be quickly recovered in case of an availability zone failure.

Disaster Recovery: This setup enables asynchronous replication between clusters, providing a robust disaster recovery solution.

Use an Existing On-Prem Nutanix Cluster as a Disaster Recovery Target:

Hybrid DR: Leveraging an existing on-premises Nutanix cluster for disaster recovery provides a cost-effective and efficient DR solution.

Replication: Set up replication policies to ensure data is consistently copied from the NC2 cluster on AWS to the on-premises cluster.

Why Not Other Options:

One-node cluster in another availability zone: Not a valid DR solution as a single-node cluster cannot provide the required resilience and high availability.

Deploy a cluster across two availability zones: While this can enhance availability, it is not a typical approach for Nutanix clusters which are designed to operate within a single availability zone for simplicity and performance reasons.

References:

Nutanix Cloud Clusters on AWS Administration Guide

Nutanix Disaster Recovery Best Practices

AWS Availability Zones and Disaster Recovery Documentation

AHV (Answer A):

AHV (Acropolis Hypervisor) can be upgraded using Lifecycle Manager (LCM). LCM simplifies the upgrade process and ensures that all components are updated in a coordinated manner.

BIOS (Answer C):

BIOS upgrades can also be performed using LCM. This helps in maintaining hardware compatibility and performance by ensuring that the latest firmware is installed.

References:

Nutanix Lifecycle Manager (LCM) Documentation

Nutanix AHV Upgrade Guide

Nutanix BIOS Upgrade Documentation
