Question # 33

Refer to the exhibit.

Packets arriving from source 209.165.200.215 must be sent with the precedence bit set to 1, and packets arriving from source 209.165.200.216 must be sent with the precedence bit set to 5. Which action resolves the issue?

set ip precedence critical in route-map Texas permit 10

set ip precedence critical in route-map Texas permit 20

set ip precedence immediate in route-map Texas permit 10

set ip precedence priority in route-map Texas permit 20

Full Access

Question # 34

Refer to the exhibit.

The R2 loopback interface is advertised with RIP and EIGRP using default values. Which configuration changes make R1 reach the R2 loopback using RIP?

R1(config)# router ripR1(config-router)# distance 90

R1(config)# router ripR1(config-router)# distance 100

R1(config)# router eigrp 1R1(config-router)# distance eigrp 130 120

R1(config)# router eigrp 1R1(config-router)# distance eigrp 120 120

Full Access

Question # 35

Refer to the exhibit.

The control plane is heavily impacted after the CoPP configuration is applied to the router. Which command removal lessens the impact on the control plane?

access-list 120 permit udp any any eq pim-auto-rp

access-list 120 permit eigrp any host 224.0.0.10

access-list 120 permit ospf any

access-list 120 permit tcp any gt 1024 eq bgp log

Full Access

Question # 36

Refer to the exhibit.

During ISP router maintenance, the network produced many alerts because of the flapping interface. Which configuration on R1 resolves the issue?

no snmp trap link-status

snmp trap link-status down

snmp trap ip verify drop-rate

ip verify drop-rate notify hold-down 60

Full Access

Question # 37

Refer to the exhibit. The administrator is troubleshooting a BGP peering between PE1 and PE3 that is unable to establish Which action resolves the issue?

P2 must have a route to PE3 to establish a BGP session to PE1

Disable sending ICMP unreachables on P2 to allow PE1 to establish a session with PE3

Ensure that the PE3 loopback address is used as a source for BGP peering to PE1

Remove the traffic filtering rules on P2 blocking the BGP communication between PE1 and PE3

Full Access

Question # 38

Refer to the exhibit An engineer must connect the Reno and Detroit spokes using DMVPN phase 2 Hub tunnel configuration is

Which configuration accomplishes the task?

Option A

Option B

Option C

Option D

Full Access

Question # 39

Refer to the exhibit.

An engineer must configure PBR on R1 to reach to 10.2.2.0/24 via R3 AS64513 as the primary path and a backup route through default route via R2 AS64513. All BGP routes are in the routing table of R1. but a static default route overrides BGP routes. Which PBR configuration achieves the objective?

Option A

Option B

Option C

Option D

Full Access

Question # 40

Refer to the exhibit. An engineer implemented an access list on R1 to allow anyone to Telnet except R2 Loopback0 to R1 Loopback4 How must sequence 20 be replaced on the R1 access list to resolve the issue?

sequence 20 permit tcp host 1001 ABC:2011:7:: 1 host 400A:0:400C::1 eq telnet

sequence 20 deny tcp host 400A:0:400C::1 host 1001 :ABC:2011:7::1 eq telnet

sequence 20 deny tcp host 1001:ABC:2011:7::1 host 400A:0:400C::1 eq telnet

sequence 20 permit tcp host 400A:0:400C::1 host 1001ABC:2011:7::1 eq telnet

Full Access
