The issue described in the scenario occurs because when creating an Access Control List (ACL) to be used for managing traffic to the Wireless LAN Controller’s (WLC) CPU, it must be explicitly defined as a CPU ACL. If this specification is not made during the creation process, the ACL will not appear in the drop-down list when enabling the CPU ACL function. This is necessary because CPU ACLs are used to protect the WLC against potential Denial-of-Service (DoS) attacks by filtering incoming packets directed at the management interface before they are processed by the CPU. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

 For a large company requiring support for 32 VLANs for different departments, the most efficient solution is to configure one single SSID and use Cisco ISE for dynamic VLAN assignment based on user roles. Cisco ISE can classify users into different groups and assign them to the appropriate VLANs. This approach reduces the complexity of managing multiple SSIDs and simplifies the user experience while maintaining a high level of security and network segmentation. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

For rogue containment on an SSID, it’s recommended to use two access points for containment (Option B). Using more than two can lead to unnecessary interference and potential disruption of service for legitimate users, while using just one may not be effective enough in containing the rogue SSID. References := ( CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide )

For RADIUS to restrict administrative control effectively, the engineer needs to define a Network Access Server (NAS) entry that corresponds to the WLC’s management IP address and the AP subnet. The correct entry would be the NAS IP of the virtual interface (typically used for RADIUS communications) and the specific network range of the AP subnet, which is 192.168.2.0 with a subnet mask of 255.255.255.0. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide.

Apple’s Fastlane technology is used to prioritize traffic from iOS devices on the network. By enabling Fastlane under each WLAN setting, the network can recognize and prioritize traffic from Apple iOS devices, addressing the QoS issues for these devices on the WLANs. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

The configuration required is to trust the DSCP (Differentiated Services Code Point) on the controller switch port. This ensures that the voice traffic’s class of service is maintained throughout the network. By trusting DSCP, the switch will preserve the DSCP value set by the wireless LAN controller, which is responsible for marking the voice packets. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide.

In a Cisco wireless LAN controller, setting a specific data rate to ‘Mandatory’ means that all wireless clients must be able to communicate at this rate. To ensure that multicast uses the 54Mbps rates, one must set the 54Mbps data rate to ‘Mandatory’. This configuration will make it so that all multicast traffic is transmitted at this minimum set data rate, thus meeting the requirement specified by the engineer.

Graphical user interface Description automatically generated
