350-601 Exam Dumps - Implementing Cisco Data Center Core Technologies (350-601 DCCOR)

The Cisco UCS firmware Auto Sync Server policy includes several configuration settings that determine how and when firmware on servers is synchronized. The two available settings from the options provided are ‘User Acknowledge’ and ‘No Action’. ‘User Acknowledge’ requires an administrator to manually acknowledge firmware upgrades in the Pending Activities dialog box before they are applied. ‘No Action’ means no firmware upgrade is initiated on the server. These settings allow administrators to control the firmware synchronization process according to their operational policies and procedures.

References := Using Firmware Automatic Synchronization Server Policy - Cisco, Cisco UCS B-Series CLI Firmware Management Guide, Release 2.2

The ‘Full State’ backup type in Cisco UCS Manager is designed to capture a snapshot of the entire system, which includes all configuration settings, system logs, and the operating system. This comprehensive backup can be used to fully restore the system in the event of a disaster recovery scenario. The ‘Full State’ backup is the only option that provides a complete system snapshot, making it the ideal choice for disaster recovery purposes.

References: The information regarding backup types and their purposes can be found in the Cisco Data Center Core Technologies source book, specifically in the section discussing system maintenance and backups within the Cisco UCS Manager platform.

POAP is an automatic provisioning and zero-touch deployment feature that assists device owners in the

initial deployment and configuration of Nexus switches.

The feature works by checking for a local configuration script. If the script has been deleted, the switch has

been reset to factory settings, or this is the first boot-up, the POAP daemon will connect to a preset list of

servers to download an initial configuration file.

To perform this operation, the switch must first obtain an IP address from a local DHCP server. POAP

configuration settings can also be passed through the DHCP response.

Which conditions should be verified, so they need to be TRUE. Like no startup (A) and bootup (B). C means

that it needs to miss a license file and E means it needs to miss an NX-OS image.

The correct configuration to capture traffic only from the server with the IP address of 198.19.1.19/24 is option C. This configuration uses an IP access list to match packets from the specific IP address with a subnet mask of 255.255.255.255, which indicates a single host. The monitor session command is then used to apply this access list to a SPAN session, ensuring that only traffic from the specified server is captured.

The src-dst-port load balancing method ensures that frames in the same flow (identified by the source and destination ports) follow the same links in a port channel. This method is effective in environments with Cisco MDS 9000 Series Switches because it maintains the order of frame delivery within a flow, which is crucial for storage traffic. Subsequent flows can use different links, allowing for efficient utilization of the port channel bandwidth. References: Implementing and Operating Cisco Data Center Core Technologies (DCCOR) course materials.

Two statements that are true about the process of performing an EPLD upgrade on a Cisco MDS 9000 series Switch are:

• If an upgrade is interrupted, the upgrade continues after a connection is restored. This means that the EPLD upgrade process is resilient to network or power failures and can resume from where it left off once the connection is reestablished.
• The upgrade can be performed from the standby supervisor module. This allows the active supervisor module to continue to provide management and control functions while the EPLD upgrade is in progress. The standby supervisor module can also take over the active role if needed during the upgrade.

The other statements are not true because:

• The active supervisor cannot be upgraded. The EPLD upgrade process requires the supervisor module to be in standby mode before it can be upgraded. The active supervisor module must be switched to standby mode manually or automatically before the upgrade can begin.
• Modules do not need to be online to be upgraded. The EPLD upgrade process can upgrade modules that are offline or powered down as well as modules that are online. The offline modules are upgraded when they are brought online or powered up.
• The upgrade process disrupts all modules that are being upgraded. The EPLD upgrade process requires a module reload for each module that is being upgraded, which causes a temporary disruption of traffic and services on that module. The disruption can be minimized by using hitless or non-disruptive EPLD upgrade modes, which preserve the forwarding state and configuration of the module during the reload. References: For more details on how to perform an EPLD upgrade on a Cisco MDS 9000 series Switch, please refer to the following resources:
• Cisco MDS 9000 Family NX-OS System Management Configuration Guide
• Cisco MDS 9000 Family EPLD Upgrade Release Notes

A screenshot of a computer Description automatically generated

To monitor all LAN traffic on Fabric A from a blade server, the source should be configured as all uplink Ethernet ports in the test-span monitor session. This configuration allows the engineer to capture all LAN traffic that traverses the uplink Ethernet ports, providing a comprehensive view of the network activity related to Fabric A. By monitoring these ports, the engineer can analyze traffic patterns, detect anomalies, and ensure the proper functioning of the network.

References :=

• Implementing and Operating Cisco Data Center Core Technologies (DCCOR) v1.2, which covers the necessary concepts for monitoring and managing traffic within a Cisco data center network.
• Cisco Data Center Network Manager (DCNM) Guide, which provides detailed instructions on setting up and configuring monitoring sessions for traffic analysis.
