350-701 Exam Dumps - Implementing and Operating Cisco Security Core Technologies (SCOR 350-701)

 NetFlow is a protocol that collects and exports information about network traffic flows. NetFlow Version 9 is the latest version supported by the Cisco ASA 5500 Series firewall. To enable NetFlow on the ASA, you need to perform two main tasks: define a NetFlow collector and apply NetFlow exporter to an interface. A NetFlow collector is a device or application that receives and processes the NetFlow records sent by the ASA. You can define a NetFlow collector by using the flow-export command, which specifies the IP address, port number, and interface of the collector. A NetFlow exporter is a configuration that determines which traffic flows are monitored and exported by the ASA. You can apply NetFlow exporter to an interface by using the Modular Policy Framework (MPF), which allows you to create class maps and policy maps to match and act on interesting traffic. You can use the flow-export event-type option in the policy map to select the NetFlow events that you want to export. The other options (B, C, and D) are not required or correct for enabling NetFlow on the ASA. You do not need to create an ACL to allow UDP traffic on port 9996, because the ASA uses a random high port number to send NetFlow records to the collector. You do not need to apply NetFlow exporter to the outside interface in the inbound direction, because you can apply it to any interface and direction that you want to monitor. You do not need to create a class map to match interesting traffic, because the ASA monitors all traffic flows by default, unless you filter them by using the flow-export filters command. References:

• Cisco Secure Firewall ASA NetFlow Implementation Guide, section “About NSEL”
• Cisco Secure Firewall ASA NetFlow Implementation Guide, section “Configure NSEL Collectors (CLI)”
• Cisco Secure Firewall ASA NetFlow Implementation Guide, section “Configure Flow-Export Actions Through Modular Policy Framework”
• Configuring NetFlow on ASA with ASDM, section “Enabling NetFlow on ASA”

 The strongest security possible for SNMPv3 requires both authentication and encryption, which is achieved by using the priv security level. Authentication ensures that the message is from a valid source, and encryption scrambles the content of the packet to prevent it from being learned by an unauthorized source. The auth sha and priv aes 256 parameters specify the algorithms used for authentication and encryption, respectively. SHA is more secure than MD5, and AES 256 is more secure than DES or 3DES. Therefore, option D is the correct answer, as it uses the priv security level, the SHA algorithm for authentication, and the AES 256 algorithm for encryption. The other options either use a lower security level (noauth or authNoPriv), a weaker encryption algorithm (des or 3des), or no encryption at all. References :=

• SNMP Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3850 Switches) - SNMP Version 3
• Configuration Template for SNMPv3 - Cisco Community
• SNMP Version 3 - Cisco

Cisco ESA uses a multilayer approach to fight viruses and malware. The first layer of defense consists of outbreak filters, which the appliance downloads from Cisco SenderBase. Outbreak filters use global threat intelligence and behavioral analysis to identify and block emerging threats before they reach the network. The second layer of defense consists of antivirus engines, which scan the message body and attachments for known viruses and malware. Cisco ESA supports multiple antivirus engines, such as Sophos, McAfee, and Cisco AMP. The Sophos engine is one of the default engines that Cisco ESA uses, along with McAfee. The Sophos engine provides fast and accurate detection of viruses and malware, and updates its signatures frequently. The other options are not features that are used to configure Cisco ESA with a multilayer approach to fight viruses and malware. A white list is a list of trusted senders or recipients that are exempt from spam or virus filtering. RAT is the Recipient Access Table, which is used to determine whether the appliance accepts or rejects messages to a recipient address. DLP is Data Loss Prevention, which is used to prevent sensitive or confidential data from leaving the network. References :=

• Email Security Using Cisco ESA
• Demystifying Cisco ESA HAT, RAT Tables and Deployment Types
• Email Security Deployment Guide - Cisco

The WSA uses a root certificate and a private key to decrypt HTTPS traffic. The root certificate must reside in the trusted store of the WSA, and it must be able to sign server certificates on the fly. The server certificates that the WSA generates must contain a SAN (Subject Alternative Name) field, which specifies the hostnames or IP addresses that the certificate is valid for. The SAN field is required by modern browsers and applications to verify the identity of the server. If the WSA does not include a SAN field in the server certificate, the browser or application may reject the connection or display a warning message.

The other options are not correct because:

• A. The current date is not a criterion for the WSA to use a certificate to decrypt application traffic. The WSA checks the validity period of the certificate, which includes the start date and the end date. The current date must be within the validity period, but it does not have to be the same as the start date or the end date.
• C. The root certificate that the WSA uses to decrypt HTTPS traffic does not have to reside in the trusted store of the endpoint. However, the endpoint must trust the root certificate in order to accept the server certificate that the WSA generates. This can be achieved by manually installing the root certificate on the endpoint, or by using a group policy or a certificate management system to distribute the root certificate to the endpoints.
• D. The root certificate that the WSA uses to decrypt HTTPS traffic does not have to be signed by an internal CA. The WSA can generate its own self-signed root certificate, or it can use a root certificate that is signed by an external CA. However, the root certificate must be trusted by the endpoints, as explained in option C.

References := : WSA Certificate Usage for HTTPS Decryption : [User Guide for AsyncOS 12.0 for Cisco Web Security Appliances - GD (General Deployment) - Create Decryption Policies to Control HTTPS Traffic]

Contiv is an open source container networking fabric that supports heterogeneous container deployments across virtual machines, bare-metal, and public or private clouds. Contiv facilitates deploying microsegmentation and multi-tenancy services with a policy-based container by allowing cloud architects and IT admins to create, manage, and enforce operational policies such as traffic isolation, bandwidth prioritization, latency requirements, and policies for L4-L7 network services. Contiv also integrates natively with Cisco infrastructure and provides consistent networking across any platform (Docker Swarm, Kubernetes, or OpenShift) and any networking backend (Layer 2, Layer 3, Overlays, or ACI mode)123. References := 1: Introducing Contiv 1.0 - The Most Powerful Container Networking Fabric 2: contivpp 3: Contiv · GitHub

The Cisco DNA Center RESTful PNP API allows external applications to interact with the Plug and Play (PNP) service of Cisco DNA Center, which automates the onboarding and provisioning of network devices. The PNP API has several endpoints for different operations, such as importing, claiming, updating, and deleting devices. The endpoint that adds and claims a device into a workflow is api/v1/onboarding/pnp-device/import, which takes a JSON payload with the device information and the workflow ID. This endpoint creates a new device entry in the PNP database and associates it with the specified workflow. The workflow defines the configuration template, image, and license to be applied to the device during the provisioning process12. References:

• 1: See How to Use the Plug and Play API in DNA Center – Part 2
• 2: Cisco DNA Center Platform User Guide, Release 2.2.3
