4A0-103 Exam Dumps - Alcatel-Lucent Multi Protocol Label Switching
Click on the exhibit.
Two LSPs traverse the path R1-R2-R3. Both LSPs are configured with facility fast reroute and link protection. When router R1 is the PLR, which router becomes the Merge Point (MP) for this LSP?
Click on the exhibit button below.
Which fields in this output uniquely identify the RSVP session belonging to a single LSP? (Choose three)
Click on the exhibit.
A fully loose LSP "toR6" is enabled with FRR protection. All links have the same cost. After the link between R2 and R4 goes down, FRR protection repairs the LSP and traffic traverses on R1-R2-R7-R8-R4-R6. Which of the following about this CSPF-enabled LSP on an Alcatel-Lucent 7750 SR is TRUE?
Which of the following is NOT required to configure an Alcatel-Lucent 7750 SR as a PE router running 6PE?
Click on the exhibit button below. Assume the following:
- The protected path is R1-R2-R3-R6.
- Fast reroute one-to-one protection is enabled.
If the original LSP already has two labels, and router R2 has failed, how many labels will there be in packets on the detour path?
An Alcatel-Lucent 7750 SR has its TE update threshold enabled with the up threshold set to 40%. The maximum reservable bandwidth on the link is 200M and 30M have already been reserved. When will a TE update be sent on this link?
