The Adjacency-SID sub-TLV extension is advertised within TLV-22 (Extended IS Reachability) to label a specific link in a segment routing domain. This allows for the identification and utilization of specific paths or links within the network, facilitating more efficient routing and traffic management. References := Implementing and Operating Cisco Service Provider Network Core Technologies

The correct configuration for deploying VRF on ASBR router R1 to have connectivity over an MPLS VPN inter-AS Option AB network is found in option C. This involves configuring the interface with the commands shown, including setting the interface ethernet, applying IP VRF forwarding, and enabling MPLS BGP forwarding. These steps ensure that the interface is properly configured for VRF and can support MPLS VPN inter-AS communications effectively. References := Implementing and Operating Cisco Service Provider Network Core Technologies

 In Cisco Service Provider Network Core Technologies, an EVPN instance can be likened to a VRF (Virtual Routing and Forwarding). A VRF allows multiple instances of a routing table to co-exist within the same router at the same time. Similarly, EVPN provides separation between routing instances which aligns with how VRF operates.

The task requires the engineer to configure a route map that permits all unmatched routes during router redistribution within BGP. The correct action is to remove the implicit deny entry at the end of the route map, as indicated in Option C. By default, route maps have an implicit deny at the end, meaning that if a route doesn’t match any of the permit or deny statements in the route map, it will be denied. Removing this implicit deny entry ensures that all unmatched routes are permitted. References := Implementing and Operating Cisco Service Provider Network Core Technologies

The command “traceroute mpls ipv4 10.20.0.1/32 ttl 4” is used to trace the route that packets take to get from the source to the destination in an MPLS network, specifically for IPv4 addresses with a maximum of 4 hops (Time To Live). This command will provide information on all labels and hop-by-hop IP addresses for the specified destinations, meeting the requirements stated in the question.

References := For more detailed information, you can refer to the Implementing and Operating Cisco Service Provider Network Core Technologies training, which covers the configuration, verification, troubleshooting, and optimization of Service Provider IP network infrastructures, including MPLS operations

The absence of routes learned by PE4 from PE5 in other PE routers’ routing tables is likely due to missing route target configurations. Route targets are crucial for importing and exporting VPN routes between VRFs in MPLS Layer 3 VPNs.

• Option D is correct because advertising the route targets for PE5 to the other PEs will allow them to import routes from PE5 into their respective VRFs, facilitating communication across the Layer 3 VPN.

References :=

• Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) source book and study guide.
