The application control engine on a FortiGate next-generation firewall is responsible for identifying and managing application traffic. It allows administrators to set policies based on application types, regardless of the port or protocol being used.

If the SD-WAN traffic logs do not show the specific SD-WAN rule name, it likely means that FortiGate is using the default or implicit SD-WAN rule to balance traffic. The implicit rule comes into effect when no explicit SD-WAN rule is matched, and as a result, the SD-WAN rule name is not displayed in the logs. The default behavior is to load balance the traffic across available interfaces based on SD-WAN strategy.

FortiGate's SD-WAN rule strategies for member selection include the following:

Manual with load balancing: This strategy allows an administrator to manually configure which SD-WAN member interfaces to use for specific traffic.

Lowest Cost (SLA) with load balancing: This strategy prioritizes the link with the lowest cost that meets the SLA requirements.

Best Quality with load balancing: This strategy selects the link with the best performance metrics, such as latency, jitter, or packet loss.

Options D and E are incorrect because "Lowest Quality" is not a valid strategy, and "Lowest Cost without load balancing" contradicts the requirement for load balancing in the strategy name.

References:

FortiOS 7.4.1 Administration Guide: SD-WAN Rule Strategies

The SSL VPN is configured to listen on port 11443 on the FortiGate device, as shown in the SSL VPN settings in the exhibit. However, the user is attempting to connect to the server using port 1443, as displayed in the VPN connection status. The mismatch between the ports is causing the connection failure. To resolve this, the user should change the client configuration to use port 11443 to match the FortiGate SSL VPN configuration.

To resolve the issue of PC3 not being able to access the internet, the administrator needs to adjust the IP pool configuration or the firewall policy. The following two options will fix the connectivity issue:

B. In the IP pool configuration, set the ending IP to 192.2.0.12: The current IP pool range is 192.2.0.10-192.2.0.11, which only provides two IP addresses for network address translation (NAT). To allow PC3 to access the internet, the IP pool should be expanded to include an additional IP address by changing the end of the range to 192.2.0.12.

D. In the IP pool configuration, set type to overload: Instead of using a one-to-one NAT, changing the type to overload will allow multiple internal addresses (such as PC1, PC2, and PC3) to share a single external IP address. This will solve the issue without needing additional public IP addresses.

The other options are not suitable:

A. In the firewall policy configuration, add 10.0.1.3 as an address object in the source field: This option is unnecessary since the firewall policy already allows all addresses from the source (LAN port3).

C. Configure another firewall policy that matches only the address of PC3 as the source, and then place the policy on top of the list: This option is redundant and would not resolve the underlying issue with the IP pool configuration.

References

FortiOS 7.4.1 Administration Guide - Configuring Firewall Policies, page 512.

FortiOS 7.4.1 Administration Guide - Configuring NAT with IP Pools, page 518.

FortiGate continues to run critical security actions, such as quarantine.

Even in conserve mode, FortiGate prioritizes critical security functions to ensure basic protections are still in place, such as quarantining malicious traffic.

FortiGate continues to transmit packets without IPS inspection when the fail-open global setting in IPS is enabled.

When the system is in conserve mode and the "fail-open" setting is enabled, FortiGate will allow traffic to pass without IPS inspection to ensure traffic flow continuity despite resource limitations.

The "d-wan" zone in FortiGate SD-WAN configuration is the default SD-WAN zone created when SD-WAN is enabled. This zone contains all the interfaces assigned to SD-WAN and is essential for the functionality of the SD-WAN feature. The "d-wan" zone cannot be deleted because it is required for SD-WAN operations. Option A is incorrect because the underlay zone does not contain port1. Options B and D are incorrect because they incorrectly describe the configuration of zones.

References:

FortiOS 7.4.1 Administration Guide: SD-WAN Zone Configuration

When SD-WAN is enabled on FortiGate, the load balancing algorithm for Equal-Cost Multi-Path (ECMP) is configured using the load-balance-mode parameter under SD-WAN settings. However, if SD-WAN is disabled, the ECMP load balancing algorithm can be configured under config system settings. This flexibility allows FortiGate to control traffic routing behavior based on the network configuration and requirements.

References:

FortiOS 7.4.1 Administration Guide: ECMP Configuration
