Understanding the Command Components:

This is a Huawei CLI command used for diagnosing connectivity within a VPN instance in an MPLS network.

ping -aX → Specifies the source IP address (X) of the ping packets.

-cY → Specifies the number of ICMP Echo Request packets to send (Y).

-sZ → Defines the size (in bytes) of each ICMP Echo Request packet (Z).

-vpn-instance M → Specifies the VPN instance (VRF) M to which the ping packets belong.

Why are all options correct?

✅ A. The source IP address of the ping packets is X.

The -aX option forces the ping to originate from IP X instead of the default interface IP.

✅ B. The ping packets belong to VPN instance M.

The -vpn-instance M option ensures the ping is sent within VPN instance M, allowing verification of MPLS L3VPN routing.

✅ C. During the ping operation, the quantity of ICMP Request packets is Y.

The -cY parameter sets the number of ICMP Echo Requests to be sent, making Y the total count.

✅ D. The size of each ICMP Request packet for the ping operation is Z bytes.

The -sZ parameter defines packet size, helping to test MTU (Maximum Transmission Unit) issues.

Real-World Application:

Verifying MPLS VPN connectivity: Ensure customer networks are reachable within separate VRFs.

Testing MTU & fragmentation: Using -sZ, operators can check if packet fragmentation occurs.

Debugging asymmetric routing issues: By forcing -aX, engineers can trace return paths.

✅ Reference: Huawei HCIE-Datacom Official Guide – MPLS VPN Troubleshooting & Ping Options

When Spanning Tree Protocol (STP) is not enabled on a network, loops can occur in Layer 2 Ethernet networks, leading to various network issues. STP is designed to prevent loops by blocking redundant paths, and its absence can cause broadcast storms, MAC address table instability, and resource exhaustion. Let’s analyze each option in the context of Huawei HCIE Datacom documentation and network behavior:

A. A loop alarm is generated on the LAN switch.

This option is incorrect. Huawei switches, as per HCIE Datacom standards, do not automatically generate a specific "loop alarm" unless configured with loop detection features (e.g., Huawei’s Loop Detection Protocol or similar mechanisms). Without STP or loop detection enabled, the switch may not explicitly generate an alarm for a loop; instead, it will exhibit symptoms like broadcast storms or flapping MAC entries. Therefore, this is not a direct symptom of an STP-less loop. Reference: Huawei HCIE Datacom V3.0 Training Materials, Section 4.2 – Spanning Tree Protocol and Loop Prevention.

B. CPU usage is too high.

This option is correct. When a loop occurs without STP, broadcast packets (and sometimes multicast or unknown unicast packets) circulate endlessly in the network. This leads to excessive processing by switches as they handle these packets, resulting in high CPU usage. Huawei switches, as described in HCIE Datacom documentation, can experience CPU overload due to continuous packet forwarding and processing in a looped environment. Reference: Huawei HCIE Datacom V3.0, Chapter 5 – Switch Performance and Loop Management.

C. MAC entries flap.

This option is correct. In a loop without STP, switches continuously receive frames from multiple ports, causing MAC address tables to update repeatedly as the same MAC address appears on different ports. This "flapping" of MAC entries destabilizes the network and can lead to incorrect frame forwarding. Huawei HCIE Datacom emphasizes MAC address table stability as a critical aspect affected by loops, as outlined in Section 4.3 – Ethernet Switching and Loop Mitigation. Reference: Huawei HCIE Datacom V3.0, Section 4.3.

D. Host receives a large number of broadcast packets.

This option is correct. A loop without STP causes broadcast packets to circulate indefinitely, creating a broadcast storm. Hosts connected to the network will receive an overwhelming number of these packets, potentially leading to performance degradation or even network timeouts. This is a well-documented symptom in Huawei HCIE Datacom training, specifically in discussions about loop prevention mechanisms. Reference: Huawei HCIE Datacom V3.0, Chapter 4 – Layer 2 Loop Prevention.

Thus, the correct symptoms of a loop occurring due to the absence of STP include high CPU usage, flapping MAC entries, and hosts receiving a large number of broadcast packets. Option A is incorrect as it requires specific loop detection configuration, which is not implied in the question.

References:

Huawei HCIE Datacom V3.0 Training Materials, Sections 4.2, 4.3, and 5 – Spanning Tree Protocol, Loop Prevention, and Switch Performance.

Huawei Official Documentation on Ethernet Switching and Loop Management, available in HCIE Datacom Certification Guides (2023 update).

Understanding screen-length Command in Huawei Devices

🔹 What Does screen-length Do?

Controls how much output is displayed at a time on the Huawei CLI.

By default, command output is paginated (split-screen display).

screen-length 0 temporary disables the split-screen display, allowing continuous output without pauses.

Analysis of Each Option:

❌ A. Performing automatic word wrap → Incorrect

This command does not wrap long text lines, it controls screen pagination.

❌ B. Performing split-screen display → Incorrect

This command disables split-screen display, not enables it.

✅ C. Canceling split-screen display → Correct

This allows continuous command output without "Press Enter to continue" interruptions.

❌ D. Canceling automatic word wrap → Incorrect

Word wrap behavior is not controlled by screen-length.

Real-World Application:

Automated Network Monitoring: Used in Python scripts for uninterrupted CLI output collection.

Log Analysis: Helps in extracting large command outputs for troubleshooting.

✅ Reference: Huawei HCIE-Datacom Guide – CLI Configuration and Automation with Paramiko

Understanding BGP EVPN Route Types for VXLAN

🔹 BGP EVPN (Ethernet VPN) is used for VXLAN control-plane learning.

✅ EVPN Type 2 Route (MAC/IP Advertisement)

Carries: MAC + Host IP

Used for: L2 forwarding, Host Mobility

✅ EVPN Type 5 Route (IP Prefix Advertisement)

Carries: Network segment (Subnet) + Prefix

Used for: VXLAN L3 routing

🔹 What Do the Given Route Entries Show?

0:172.16.2.0/24

0:172.16.13.0/24

0:192.168.122.0/30

👉 These are IPv4 Subnets, NOT individual MACs.👉 Since they carry IP Prefixes, they belong to EVPN Type 5.

Analysis of the Answer Choices:

✅ A. These routes are Type 5 routes and carry network segment or mask information.

Correct: The displayed routes carry network prefixes, which belong to EVPN Type 5.

❌ B. These routes are Type 2 routes and carry host IP addresses.

Incorrect: Type 2 routes carry MAC + Host IP, NOT full subnets.

❌ C. These routes carry the L2VNI.

Incorrect: L2VNI is for Layer 2 VXLAN bridging, but these are IP Prefix Routes (L3 routing).

✅ D. These routes carry the L3VNI.

Correct: Type 5 routes are used for VXLAN L3 routing, which means they belong to L3VNI.

Real-World Application:

VXLAN L3 Gateways: Type 5 routes enable distributed routing between VXLAN segments.

Data Center Networks: Used to interconnect virtual machines (VMs) across different subnets.

✅ Reference: Huawei HCIE-Datacom Guide – BGP EVPN & VXLAN L3 Routing

Understanding HTTP/1.1 Response Headers

🔹 What is an HTTP Response?

When a web server responds to an HTTP request, it sends an HTTP response message.

The response contains headers, a status line, and a response body.

Elements of an HTTP Response Header:

✅ A. Status Code → Correct

Indicates the response status (e.g., 200 OK, 404 Not Found).

✅ B. Reason Phrase → Correct

Provides a human-readable explanation of the status code (e.g., OK, Not Found).

✅ C. Protocol Version → Correct

Specifies which HTTP version is being used (e.g., HTTP/1.1).

❌ D. Response Method → Incorrect

The HTTP method (GET, POST, etc.) is part of the request, not the response.
