Understanding Subnetting:

The subnet mask 255.255.255.240 (or /28) indicates that each subnet has 16 IP addresses (14 usable addresses, 1 network address, and 1 broadcast address).

Calculating the Subnet Range:

Subnet Calculation: For the IP address 10.0.0.95 with a /28 subnet mask:

Network address: 10.0.0.80

Usable IP range: 10.0.0.81 to 10.0.0.94

Broadcast address: 10.0.0.95

Router Interface Configuration:

Broadcast Address Issue: The IP address 10.0.0.95 is the broadcast address for the subnet 10.0.0.80/28. Configuring a router interface with the broadcast address will cause routing issues as it is not a valid host address.

Comparison with Other Options:

The web server is in a different subnet: The web server (10.0.0.81) is within the same subnet range (10.0.0.80/28).

The IP address space is a class A network: While 10.0.0.0 is a Class A network, this does not explain the routing issue caused by the broadcast address.

The subnet is in a private address space: The private address space designation (RFC 1918) does not impact the routing issue related to the broadcast address configuration.

Resolution:

Reconfigure the router interface with a valid host IP address within the usable range, such as 10.0.0.94.

References:

CompTIA Network+ study materials on subnetting and IP address configuration.

Troubleshooting Methodology:

Troubleshooting involves a systematic approach to diagnosing and resolving issues. It typically includes steps such as identifying symptoms, gathering information, formulating and testing theories, and implementing solutions.

Confirming a Theory:

Duplicate the Problem: To confirm a theory, the technician should reproduce the problem in a controlled environment. This helps verify that the identified cause actually leads to the observed issue.

Verification: By duplicating the problem, the technician can observe the issue firsthand, validate the hypothesis, and rule out other potential causes.

Comparison with Other Steps:

Identify the Symptoms: Initial step to understand what the problem is, not specifically for confirming a theory.

Gather Information: Involves collecting data and details about the issue, usually done before formulating a theory.

Determine Any Changes: Involves checking for recent changes that could have caused the issue, a part of the information-gathering phase.

Implementation:

Use similar equipment or software in a test environment to recreate the issue.

Observe the results to see if they match the original problem, thereby confirming the theory.

References:

CompTIA Network+ study materials on troubleshooting methodologies and best practices.

Understanding the 169.254.x.x Address:

An IPv4 address in the range of 169.254.x.x is an Automatic Private IP Addressing (APIPA) address, assigned when a DHCP server is unavailable.

DHCP Server Offline:

APIPA Assignment: When a device cannot obtain an IP address from a DHCP server, it assigns itself an APIPA address to enable local network communication. This allows communication with other devices on the same local subnet but not with external networks.

Resolution: Ensure the DHCP server is operational. Check for connectivity issues between the virtual machine and the DHCP server, and verify the DHCP server settings.

Comparison with Other Options:

The subnet mask is incorrect: The subnet mask 255.255.0.0 is appropriate for the 169.254.x.x range and does not prevent external access by itself.

The IP address is an RFC1918 private address: RFC1918 addresses are private IP ranges (10.x.x.x, 172.16.x.x-172.31.x.x, 192.168.x.x) but 169.254.x.x is not one of them.

The DNS server is unreachable: While this could affect name resolution, it would not prevent the assignment of a non-APIPA address or local network communication.

Troubleshooting Steps:

Verify the DHCP server’s status and connectivity.

Restart the DHCP service if necessary.

Renew the IP lease on the virtual machine using commands such as ipconfig /renew (Windows) or dhclient (Linux).

References:

CompTIA Network+ study materials on IP addressing and DHCP troubleshooting.

Using a /30 subnet mask is the most efficient way to conserve IP space for a point-to-point connection between two routers. A /30 subnet provides four IP addresses, two of which can be assigned to the router interfaces, one for the network address, and one for the broadcast address. This makes it ideal for point-to-point links where only two usable IP addresses are needed.References: CompTIA Network+ study materials and subnetting principles.

Disabling unused ports prevents unauthorized access and reduces the attack surface by ensuring that no inactive or unmonitored entry points are available for exploitation. Changing default passwords is critical for security because default credentials are widely known and can easily be exploited by attackers. These techniques are fundamental steps in hardening devices against unauthorized access and ensuring network security. References: CompTIA Network+ Exam Objectives and official study guides.

Role of the Hosts File:

The hosts file is a local file on a computer that maps hostnames to IP addresses. It can be used to override DNS resolution by providing a static mapping of a hostname to an IP address.

Common Issues with the Hosts File:

If an incorrect IP address is mapped to a hostname in the hosts file, it can cause the computer to resolve the hostname to the wrong IP address. This can lead to navigation issues for specific websites while other users, relying on DNS, do not face the same problem.

Why Other Options are Less Likely:

Self-signed certificate: Relates to SSL/TLS and would cause a security warning, not a navigation failure.

Nameserver record: Affects all users, not just one.

IP helper: Used to forward DHCP requests and is unrelated to DNS resolution issues.

Troubleshooting Steps:

Check the hosts file on the affected user's computer (C:\Windows\System32\drivers\etc\hosts on Windows or /etc/hosts on Unix/Linux).

Look for entries that map the problematic hostname to an incorrect IP address and correct or remove them.

References:

CompTIA Network+ study materials and system administration documentation.

Introduction to Administrative Distance

Administrative distance (AD) is a value used by routers to rank routes from different routing protocols. AD represents the trustworthiness of the source of the route. Lower AD values are more preferred. If a router has multiple routes to a destination from different sources, it will choose the route with the lowest AD.

Static Routes and Backup Routes

When a dynamic routing protocol is not used, static routes can be employed. Static routes are manually configured routes. To ensure a backup route, multiple static routes to the same destination can be configured with different AD values.

Configuring Static Routes with Administrative Distance

The primary route is configured with a lower AD value, making it the preferred route. The backup route is configured with a higher AD value. In the event of the primary route failure, the router will then use the backup route.

Example Configuration:

plaintext

Copy code

ip route 192.168.1.0 255.255.255.0 10.0.0.1 1

ip route 192.168.1.0 255.255.255.0 10.0.0.2 10

In the above example, 192.168.1.0/24 is the destination network.

10.0.0.1 is the next-hop IP address for the primary route with an AD of 1.

10.0.0.2 is the next-hop IP address for the backup route with an AD of 10.

Verification:

After configuration, use the show ip route command to verify that the primary route is in use and the backup route is listed as a candidate for use if the primary route fails.

References:

CompTIA Network+ guide explains the concept of administrative distance and its use in static routing configuration (see page Ref 9†Basic Configuration Commands).

On the first exhibit, the layout should be as follows

Exhibit 2 as follows

Access Point Name AP2

Exhibit 3 as follows

Access Point Name AP3
