PCNSE Exam Dumps - Palo Alto Networks Certified Security Engineer (PCNSE) PAN-OS 11.0

When planning an upgrade in an environment that includes Panorama, firewalls, and log collectors, it's crucial to follow the recommended sequence to ensure compatibility and minimize disruptions. Palo Alto Networks recommends the following order:

• Upgrade Panorama: Start with Panorama because it's the central management platform. Upgrading Panorama first ensures that it's compatible with the new PAN-OS versions that the managed devices (firewalls and log collectors) will be upgraded to. Panorama must be able to support the new versions for it to manage and monitor the devices effectively.
• Upgrade the log collectors: Next, upgrade the log collectors. Since log collectors work closely with Panorama to aggregate and store logs from the firewalls, they should be upgraded after Panorama to ensure compatibility. Upgrading the log collectors ensures they can handle the log formats and features introduced in the new PAN-OS version.
• Upgrade the firewalls: Finally, upgrade the firewalls. The firewalls are the last components to be upgraded to ensure that they remain compatible with the management and log collection infrastructure. Upgrading the firewalls last minimizes the risk of compatibility issues with Panorama and log collectors.

This sequence ensures that all components are compatible and that the management and logging infrastructure can fully support the firewalls running the latest PAN-OS version.

Traffic didnt match any other policies and so landed at the implicit "deny all" policy. If it's deny all, the traffic was dropped before the application could be determined. https://knowledgebase.paloaltonetworks.com/KCSArticleDetail?id=kA10g000000ClibCAC

The compare option for a specific rule in the New App Viewer under Policy Optimizer allows an administrator to compare the applications configured in the rule with the applications seen from traffic matching the same rule. This helps the administrator to identify any new applications that are not explicitly defined in the rule, but are implicitly allowed by the firewall based on the dependencies of the configured applications. The compare option also shows the usage statistics and risk levels of the applications, and provides suggestions for optimizing the rule by adding, removing, or replacing applications12. References: New App Viewer (Policy Optimizer), PCNSE Study Guide (page 47)

Why use Security Policy Optimizer and what are the benefits?

Hover over an attribute in the table below the chart and click the arrow icon to the right of the attribute. https://docs.paloaltonetworks.com/pan-os/9-1/pan-os-admin/monitoring/use-the-application-command-center/interact-with-the-acc#id5cc39dae-04cf-4936-9916-1a4b0f3179b9

https://docs.paloaltonetworks.com/prisma/prisma-access/prisma-access-cloud-managed-admin/secure-mobile-users-with-prisma-access/explicit-proxy/explicit-proxy-how-it-works

https://docs.paloaltonetworks.com/pan-os/11-0/pan-os-new-features/networking-features/web-proxy

https://docs.paloaltonetworks.com/pan-os/10-2/pan-os-admin/high-availability/set-up-activeactive-ha/prerequisites-for-activeactive-ha

These are the two links that can be used to configure an active/active high availability pair. An active/active high availability pair consists of two firewalls that are both active and share the traffic load between them1. To configure an active/active high availability pair, the following links are required2:

• HA1: This is the control link that is used for exchanging heartbeat messages and configuration synchronization between the firewalls. It can be a dedicated interface or a subinterface. It can also have a backup link for redundancy.
• HA2: This is the data link that is used for forwarding sessions from one firewall to another in case of failover or load balancing. It can be a dedicated interface or a subinterface. It can also have a backup link for redundancy.
• HA3: This is the session owner synchronization link that is used for synchronizing session information between the firewalls in different virtual systems. It can be a dedicated interface or a subinterface. It is only required for active/active high availability pairs, not for active/passive pairs.

https://docs.paloaltonetworks.com/pan-os/10-2/pan-os-admin/zone-protection-and-dos-protection/zone-defense/packet-buffer-protection

https://docs.paloaltonetworks.com/pan-os/10-2/pan-os-admin/certificate-management/configure-an-ssltls-service-profile
