An OSPF AS-external LSA is used to describe routes to networks that are external to the OSPF Autonomous System (AS). This external route information is typically imported into OSPF by an Autonomous System Boundary Router (ASBR).

If the Forwarding Address field in the AS-external LSA is set to 0.0.0.0, this indicates that traffic destined for the external network should be forwarded directly to the ASBR that advertised the external route.

The specific context mentioned here relates to the Not-So-Stubby Area (NSSA), a type of OSPF area designed to handle AS-external routes in a more controlled way. In NSSAs:

Type 7 LSAs are used to describe AS-external routes.

The ASBR within the NSSA converts the Type 7 LSA to a Type 5 LSA before advertising it to the backbone area.

Hence, the correct acronym for the described functionality is NSSA.

References:

Huawei HCIA-Datacom Study Guide, Chapter on "OSPF Area Types".

RFC 3101 – OSPF Not-So-Stubby Area (NSSA) Option.

Goal Analysis:

Requirement:

The route to 192.168.3.0/24 must exist in R1's and R3's routing tables.

The route must not exist in R2's routing table.

This requires filtering to ensure the route is either:

Blocked on R2's routing table (via filtering on R2), or

Blocked before it is advertised to R2.

Analysis of Each Option:

Option A (Filter-policy on R2 for filtering received routes):

Applying a filter-policy on R2 to filter received routes will block the route from entering R2's routing table but still allow it to propagate to R3.

This meets the requirement.

Option B (Filter-policy on R2 for filtering the routes to be advertised):

Blocking the advertisement of routes from R2 to other routers does not affect the routes received by R2 itself.

This does not meet the requirement but does not affect the propagation to R3.

This is valid if the received route is blocked.

Option C (Filter-policy on R1 for filtering the routes to be imported):

If the route is filtered on R1 during the import phase, the route will not exist in R1’s routing table and thus cannot be advertised to either R2 or R3.

This fails to meet the requirement because the route must exist in R1's and R3's routing tables.

Option D (Filter-policy on R1 for filtering the imported routes to be advertised):

Filtering routes on R1 before advertising to R2 will prevent R2 from receiving the route but allow R1 to advertise the route to R3.

This meets the requirement.

Correct Option:

C (Filter-policy on R1 for filtering the routes to be imported): This will prevent the route from existing in both R1 and R3, violating the stated requirement.

References:

HCIA-Datacom Study Guide, Chapter: OSPF Route Filtering

Huawei OSPF Configuration and Filtering Methods

Comprehensive and Detailed Step-by-Step Explanation:

WAN Definition:

A WAN is a large-scale network spanning a wide geographical area, connecting smaller networks such as LANs and MANs.

Use Cases:

WANs are commonly used for interconnecting campus networks, branch offices, and data centers over long distances.

Correct Statement:

The statement accurately describes the purpose and scope of WANs.

References:

HCIA-Datacom Study Guide, Chapter: WAN Fundamentals

Huawei Networking Basics

The summary automatic command in BGP is used to enable automatic summarization of routes, particularly for classful networks. However, manual summarization takes precedence over automatic summarization when both are configured. This makes the statement claiming automatic summarization takes precedence false ​.

When a stack splits, the MAC addresses of the newly formed stacks do not change immediately. Instead, they retain their original MAC addresses until new ones are reassigned during topology updates. This delayed update prevents immediate conflicts and allows MAD (Multiple Active Detection) to handle any resulting issues ​.

Comprehensive and Detailed Step-by-Step Explanation:

IGMPv1 Querier Selection:

In IGMPv1, there is no built-in querier election mechanism. Querier selection depends on the multicast routing protocol (e.g., PIM).

IGMPv2 and IGMPv3 Querier Selection:

In IGMPv2 and IGMPv3, the router interface with the largest IP address in the multicast group is selected as the querier.

Correct Statement:

The statement accurately describes the querier selection mechanisms in IGMP versions.

References:

HCIA-Datacom Study Guide, Chapter: IGMP Querier Mechanism

Huawei Multicast Protocol Comparison

The DHCPNAK message is sent by the DHCP server to the client to indicate that the requested configuration is not valid. Messages like DHCPDiscover, DHCPRequest, and DHCPRelease are initiated by the client in the DHCP process ​.

Understanding DHCPv6:

DHCPv6 (Dynamic Host Configuration Protocol for IPv6) is used to assign configuration parameters to IPv6 clients.

It supports both stateful and stateless modes:

Stateful: Assigns IPv6 addresses and other configuration parameters.

Stateless: Assigns only configuration parameters (e.g., DNS server) without providing IPv6 addresses.
